Communication Business > Repeater >
Optical Repeater
LGU+_5G Active DAS Repeater
Overview

The System is an indoor device for In Building Service and 5G Active DAS device to LGU+, corresponding to LGU+ 3.5GHz.

Characteristics
  • The System consists of MU, HU, and ARU(ANT-built-in) and corresponds and supports 4*4 MIMO.
  • The Interface between MU, HU, and ARU consists of the system, usign Optic Fiber Cable(10Gbps)(RU power is supplied from HU).
  • When MU is composed by Star method, it supports to connect maximum 4 HUs per MU.
  • When HU is composed by Star method, it supports to connect maximum 8 RUs per HU(Available for maximum 32 RUs per MU)
Spec.
Item 5G Active DAS Repeater
Frequency 3400MHz ~ 3500MHz
Output Power +24dBm / 100MHz
Port 4*4 MIMO
Item Description
Dimensions (mm, W*H*D) MU : 482.6 x 44 x 400
HU : 482.6 x 44 x 365
RU : 200 x 200 x 55
Weight MU : 6Kg, HU :4.5Kg, RU : 2.5Kg
Operating Temperature -10 ~ +50℃
Cooling Natural Convection
* MU: Main Unit, ARU: Ant Remote Unit, MIMO: Multiple-Input Multiple-Output
