Interface

Downlink Port : 8 Port 10/100/1000Base-T with IEEE802.3af/at POE

Uplink Port : 2 Port  SFP (100Base-Fx or 1000Base-X)

Console Port : RS-232C RJ-45 Connector (Default 9600bps)

L2 Switching

IEEE 802.1D Bridge

Auto MAC address learning/aging and MAC addresses (static), 8K

IEEE 802.1Q static VLAN (4K)

Private VLAN (static)

Port isolation (static)

Rapid spanning tree (RSTP)

IEEE 802.3ad Link Aggregation, static and LACP

IGMPv2 snooping

DHCP client

Port Mirroring (Per-port / Per-VLAN)

G.8032 Ethernet Ring Protection Switching

QoS

Strict Priority Queue / Deficit Weighted Round-Robin

Traffic classes (1, 2, or 4/8 active priorities)

Port default priority

User priority

QoS control list (QCL mode)

Storm control for Unicast, Multicast, and Broadcast

Per-port , Policing and shaping of each queue

Ingress Rate Control (100Kbps unit)

Security

IEEE 802.1x Port-base Access Control

Authentication and authorization based on web and CLI

Filtering, policing and port copy (including ACL wizards) through ACL

Management

CLI console port

Web Management (GUI)

System syslog

SNMP v1/v2c/v3

IEEE 802.1ab LLDP

Loop detection default restore

Energy Saving Function

IEEE802.3az (Energy Efficient Ethernet)

Fan-less and zero-noise cooling, Low-power operation

Physical & Environmental

Power Input : 100-240V AC, 50/60Hz

Dimension : W:254 x D:200 x H:43.6 (mm)

Weight : 2Kg

Temperature : Operating: -20~60℃, Storage: -40~85℃

Humidity : Operatiing: 20~80%, Non-condensing

Certification : KCC A

PoE

8 Port Support, IEEE802.3at PoE+,  PSE Alternative A

Supports Max 4 30W Terminals or Mas 8 15.4W Terminals
